DJI AL1 Spotlight
Mission Accessories
Illuminate an inspection subject or search area with a spotlight that follows the aircraft camera. AL1 adds steady and strobe lighting to compatible Matrice 4 and Matrice 4D aircraft.
$473.00
USDAvailable to order
Delivery
Standard shipping is available to the contiguous 48 states and Washington, DC. Shipping charges are shown at checkout before payment. Orders of $6,500 or more after discounts qualify for free standard shipping.
Warranty & returns
Request a return within 10 days of delivery. Customers pay change-of-mind return shipping; opened change-of-mind returns have a 20% restocking fee. GroDrones covers return shipping for incorrect items, products that arrived damaged or defective, and approved warranty returns. Contact us before shipping a return. See our return policy.
- 32 W
- Maximum power
- Steady + strobe
- Lighting modes
- 328 ft (100 m)
- Reference illumination distance
Overview
Gimbal-linked aiming keeps the light aligned with the camera view. Normal and wide-angle illumination modes give crews a choice between a concentrated subject view and broader coverage. AL1 can be used alone or with the separately sold AS1 speaker.
Official resources
DJI specifications ↗ · DJI installation and operating manual ↗
What’s included
Included items and compatible accessories.
What’s included?
- AL1 Spotlight × 1
- Spare screw × 2
- Hex key × 1
Aircraft and AS1 speaker are sold separately.
Compatibility and setup
DJI Matrice 4 Series and Matrice 4D Series. Power off the aircraft before installation, and remove the lower adapter bracket for Matrice 4D. Activate the spotlight and keep firmware current. Installing AL1 reduces left/right obstacle avoidance and disables bypass on Matrice 4; upward obstacle avoidance is disabled on Matrice 4D. Turning on the light disables obstacle avoidance. Flight time is reduced. If adding AL1 to an installed AS1 speaker, recalibrate the compass as directed. Keep the light away from eyes and handle hot surfaces carefully.
Specifications
The details that matter when choosing your equipment.
| Supplier SKU | CP.EN.00000579.01 |
|---|---|
| Weight with mounting bracket | 3.49 oz (99 g) |
| Dimensions with bracket | 3.74 × 6.46 × 1.18 in (95 × 164 × 30 mm) |
| Maximum power | 32 W |
| Illuminance at 328 ft (100 m) | 4.3 ± 0.2 lux, under DJI laboratory conditions |
| Operating temperature | -4 to 122°F (-20 to 50°C) |
Illuminance was measured with the spotlight installed separately at 77°F (25°C). Actual coverage varies with conditions and configuration.
