DJI Matrice 4D Series 240W Charging Hub
Batteries & Charging
Connect up to three Matrice 4D-series batteries and charge them in sequence. Choose a full charge or a ready-to-fly target for deployment.
$144.00
USDAvailable to order
Delivery
Standard shipping is available to the contiguous 48 states and Washington, DC. Shipping charges are shown at checkout before payment. Orders of $6,500 or more after discounts qualify for free standard shipping.
Warranty & returns
Request a return within 10 days of delivery. Customers pay change-of-mind return shipping; opened change-of-mind returns have a 20% restocking fee. GroDrones covers return shipping for incorrect items, products that arrived damaged or defective, and approved warranty returns. Contact us before shipping a return. See our return policy.
- 3 batteries
- Connected capacity
- Sequential
- One battery after another
- 100% or 90%
- Standard or Ready-to-Fly target
Overview
The hub starts with the battery carrying the highest charge. Standard Mode fills each pack to 100%; Ready-to-Fly Mode charges and maintains each at 90%. Use the compatible DJI power source and keep batteries on the correct series of hub.
Official resources
What’s included
Included items and compatible accessories.
What’s included?
- Charging hub × 1
- SDC cable × 1
240W power adapter, portable power station and batteries are sold separately.
Compatibility and setup
Matrice 4D and Matrice 4TD batteries only. Use the DJI 240W Power Adapter or the supported DJI Power connection specified by DJI. This is not the hub for Matrice 4E/4T batteries. The USB-C port is for firmware updates, not battery charging; use the SDC charging connection.
Specifications
The details that matter when choosing your equipment.
| Supplier SKU | CP.EN.00000627.01 |
|---|---|
| Model | CHX230-240 |
| Compatible battery | BPX230-6768-22.14 |
| Input | 16.8–25.5 V, maximum 12.1 A |
| Rated power | 240 W |
| Operating temperature | 41 to 104°F (5 to 40°C) |
